Transcript

00:00 Before we start digging deeper into tree data structures

00:02 and algorithms, we need to cover some basic maths

00:05 around boundary trees and tree data structures in general.

00:08 This will help us appreciate the advantages

00:10 of using a tree data structure in an algorithm.

00:13 So let's go Now

00:16 before I scare you away with terms like trees

00:18 and graphs, we've actually already looked at a graph

00:21 on this particular channel.

00:22 When we looked at the link list data structure,

00:25 a link list is actually an example

00:27 of a graph data structure.

00:28 A graph is nothing more than a set

00:30 of nodes pointing to other nodes.

00:32 In the case of a link list, we have a head node pointing

00:35 to the next node via its next member and so on

00:38 and so forth till we eventually arrive at an null value.

00:42 Now a graph is a very general data structure

00:44 and it includes pretty much any data structure.

00:46 We have nodes pointing to other nodes.

00:50 So by this definition, the link list data structure

00:53 that we looked at is a graph.

00:55 Now a tree data structure is just a specialization

00:57 of the graph with a few restrictions,

01:00 and you could argue that the link list data structure

01:02 is a tree as well.

01:04 But let's look at a more general representation of

01:07 what people imagine when they think of a tree.

01:09 Fundamentally, the restrictions we impose on a graph for it

01:12 to be considered a tree is

01:14 that it must not contain any cycles.

01:17 There is normally a node called the root,

01:20 and from this root node we can actually make our path

01:23 to any other nodes within the tree.

01:26 Now, in order to better analyze the mathematics

01:28 around tree data structures, we will start off

01:30 with a simpler tree than this one.

01:32 There are two things that we will simplify.

01:35 First, we will only consider a balanced tree.

01:38 The tree that we are looking at right now is imbalanced.

01:41 This is because we've added a few leaf nodes

01:43 that are way off on one side without filling up the nodes

01:46 that are further up within the tree.

01:48 The other simplification that we will make is

01:50 that we will consider only a pinery tree.

01:53 This tree that we have over here is not a binary tree

01:56 as there are nodes that contain more than two

01:58 children and a binary tree.

02:00 Each node has only two children.

02:02 So here is the reference completely balanced binary tree

02:05 that we will use to analyze tree data structures.

02:09 Now before we jump into any formulas,

02:11 let's first analyze this tree a bit more to understand

02:14 how the number of nodes grow within each level of the tree.

02:18 Now just from visual observation of the tree, you can see

02:21 that at level zero we have one node resulting in total

02:24 count of one.

02:25 Within level one, we have two nodes within that level, along

02:29 with one node from the previous level, resulting in a total

02:32 of three nodes.

02:34 Similarly, at level two we have four

02:36 with four plus three giving us a total of seven.

02:39 And at level three we have eight nodes, which combined

02:42 with the previous seven result in a total of 15.

02:45 Now we could continue, but this should be enough for us

02:47 to understand a general pattern.

02:50 Now the first thing that we can notice is

02:52 that at each double, the number of nodes essentially double.

02:55 So we start off at level zero with one node,

02:58 and then in level one we get two.

03:00 In level two we get four and so on.

03:02 And this makes perfect sense because

03:04 after all, this is a boundary tree

03:06 and each node in the previous level essentially has two

03:09 children resulting in double the number of nodes.

03:11 And now the other observation that we can make

03:13 that is perhaps not as obvious if you haven't experienced it

03:16 before, is that the total number

03:18 of nodes in the previous level is actually one minus the

03:22 number of nodes in the current level.

03:24 We can see this in the relationship between two

03:26 and one, four and three and eight and seven.

03:30 Now, armed with these observations, we can write the formula

03:33 for the total at any given level as to the power L,

03:37 that is the current number of nodes plus two

03:39 to the power L minus one.

03:40 That is the number of nodes

03:42 that we get from the previous total.

03:44 As an example, consider level three

03:46 where we have eight current nodes, which is simply two

03:49 to the power three combined with seven nodes, which is two

03:53 to the power three minus one from the previous level,

03:56 resulting in a total number of nodes of 15.

03:59 Now we can combine the two two to the power Ls to get two

04:03 to the power L plus one.

04:05 Now we've been working with the zero based index

04:07 for the level, but we can take this l plus one

04:09 and come up with a new concept known as the height

04:12 of a tree, which is simply going to be a plus one.

04:15 We just start our index at value one.

04:18 So with that, we have a nice relationship between the height

04:21 of the tree versus the number of items

04:23 that it can accommodate.

04:25 Now why is this relationship useful?

04:27 If you look at the tree data structure quite commonly

04:29 what we will be doing is you'll be searching only

04:32 between the height of the tree instead of going through all

04:34 of the nodes within the tree.

04:36 So if N is the number of nodes in the tree

04:38 and itches the height, instead of having to look at n items,

04:41 we would only need to look at etch items.

04:44 So let's figure out the equation for etch.

04:46 Right now we know the equation for N to be two

04:48 to the power etch minus one.

04:51 We simply flip the equation around

04:52 to bring etch on the left hand side,

04:54 move minus one onto the right hand side,

04:56 and then take log on both sides to get just etch.

05:00 On the left hand side. This gives us edge is equal

05:03 to log two of n plus one.

05:05 Now, when we talk about algorithms, we rarely deal

05:07 with exact equations

05:08 and we normally talk about big annotation because

05:11 after all, we don't take into consideration the differences

05:14 in the different processes,

05:15 which if you don't take quantum computing into account is

05:18 probably going to be a constant factor difference.

05:21 So RH is equal to log two of n plus one is the same as O

05:24 of H is equal to log of n.

05:27 Note that big O does not care about that plus one

05:30 or the base of that log.

05:31 Now that's it for the analysis

05:33 of a perfectly balanced binary tree, but let's go back

05:36 and modify some of our assumptions

05:37 to make this even more general.

05:39 For more three data structures, the first thing

05:42 that we will look at is a constant factor of imbalance.

05:46 For example, this particular tree is twice

05:48 as heavy on the left hand side versus the right hand side,

05:50 which means that in the worst case scenario, it's going

05:53 to be twice as high than our perfectly,

05:55 perfectly balanced tree

05:56 That we looked at in our previous example.

05:59 Now if you can make the guarantee that it's never going

06:01 to exceed twice

06:03 as heavy imbalance on one side versus the other, then as far

06:07 as big O algorithmic analysis is concerned,

06:09 this tree is perfectly balanced

06:11 as big O does not care about constant factors like two,

06:16 maintaining a maximum worst case imbalance essentially makes

06:19 trees balanced as far as pego is concerned.

06:23 And the other key assumption that we made for our tree is

06:25 that it is a binary tree

06:27 that is each node has only two children.

06:30 That is not an assumption that is true

06:32 for many tree data structures out there.

06:34 For example, here is a quarter

06:36 where each node has four children,

06:39 and the only thing that will change in our analysis is

06:41 that instead of log two, we will end up

06:43 with some form of log four.

06:46 Now for those that are familiar with log functions,

06:48 the difference between two log functions

06:50 that have a different base is actually just a

06:53 simple factor difference.

06:54 For example, the difference

06:55 between log two versus log four is this factor

06:58 log two of four.

07:00 And as far as a big O is concerned once more,

07:03 it really doesn't care about a constant factor and

07:05 therefore doesn't really care about log basis.

07:07 And it'll be the same as log of N that we saw previously.

07:13 So to summarize, if you solve a problem using a tree data

07:16 structure that is partially balanced

07:18 and you only need towards the height of the tree as far

07:21 as your runtime is going to be concerned, it's going

07:23 to be approximately log of the number of items in the tree.

07:27 And if anybody ask you whether this is a great thing,

07:29 you can throw a few numbers.

07:31 For example, you can say that the log 10 of 10 is one,

07:34 and the log 10 of a thousand,

07:36 which has three zeros is going to be three.

07:38 Similarly, the log 10 of a million is going to be six

07:42 and log 10 of a billion is going to be nine.

07:44 So you can see that it is increasing extremely slowly.

07:47 And the same is true for other log bases as well

07:50 because as we've discussed the difference

07:52 between two log functions that have a different base,

07:55 it's a constant factor.

07:56 So log two of a billion is still going to be approximately

07:59 around 30.
